- Hohes Drehmoment bei niedrigen Drehzahlen
- Konfiguration ohne Lager für Anwendungen, bei denen die Last bereits von eigenen Lagern unterstützt wird
- Dauerdrehmomentleistung von 32,7 Nm bis 426 Nm (289 lb/in bis 3770 lb/in)
- Vereinfachte Mechanismen und geringere Teileanzahl mindern Ausfallzeit und Instandhaltung
- Nahtlose Integration in unsere Integrated-Architecture-Lösung mit einer einzigen Umgebung zur Programmierung, Steuerung und Datenerfassung
- High-Resolution-Absolut-Encoder mit Single- und Multi-Turn-Option von Heidenhain
- Optimierte Wicklungen für den Einsatz von unseren Kinetix®-Servoantrieben
- Schutzeigenschaft bis IP65
- Product Selection
- Overview
- Documentation
Product Selection
Angezeigt
1
-
24
von
41
Ergebnisse
RDB-B29034-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 3 Magnet Stacks, 200 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29039-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 3 Magnet Stacks, 750 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B41014-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 410mm BDC, 1 Magnet Stack, 200 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B41016-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 410mm BDC, 1 Magnet Stack, 375 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B41018-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 410mm BDC, 1 Magnet Stack, 625 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B41018-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 410mm BDC, 1 Magnet Stack, 625 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B41024-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 410mm BDC, 2 Magnet Stacks, 200 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B41035-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 410mm BDC, 3 Magnet Stacks, 250 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B41035-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 410mm BDC, 3 Magnet Stacks, 250 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B21519-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 215mm BDC, 1 Magnet Stack, 750 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B2152C-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 215mm BDC, 2 Magnet Stacks, 1500 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B21539-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 215mm BDC, 3 Magnet Stacks, 750 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B21539-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 215mm BDC, 3 Magnet Stacks, 750 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B2153C-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 215mm BDC, 3 Magnet Stacks, 1500 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B2153C-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 215mm BDC, 3 Magnet Stacks, 1500 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29016-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 1 Magnet Stack, 375 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29016-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 1 Magnet Stack, 375 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29019-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 1 Magnet Stack, 750 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29024-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 2 Magnet Stacks, 200 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29024-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 2 Magnet Stacks, 200 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29026-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 2 Magnet Stacks, 375 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29029-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 2 Magnet Stacks, 750 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29029-7B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 2 Magnet Stacks, 750 RPM, Multi-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
RDB-B29034-3B72AA
RDD-Series RDB 480V AC Rotary Servo Mtr
active mature
Product
Bulletin RDB - Bearingless Rotary Direct Drive Servo Motor, 400V Class, Frame Size 290mm BDC, 3 Magnet Stacks, 200 RPM, Single-turn High-Resolution Heidenhain, IP65 Housing / Blind Bore, Circular, Right Angle connector, 180° Rotatable, DIN, No Brake
