| Cable Length in Meters |
6,4M-7M
|
|---|
| Number of poles |
5
|
|---|---|
| Degree of protection (IP), mounted |
IP67
|
| Number of pins |
Standard 5-pin
|
| Second end conductors |
Standard 5 leads
|
| Number of conductors |
1 pair 15 AWG, 1 pair 18 AWG and drain
|
| Enclosure type rating |
NEMA 1, 2, 3, 4, 6P, 12, 13, IP67, 1200 psi (8720 kPa) washdown
|
| First end connector style |
Mini, straight male
|
| Cable diameter |
Thick: 12.2 mm, ODVA Type V: 13.5 mm
|
| Cable type |
Thick media, grey PVC
|
| Material |
Coupling nut: Epoxy-coated Zinc, jacket: grey PVC, contact: Gold-plated machined Brass
|
| Bend radius |
10 x diam
|
| Cable length |
6000 mm
|
|---|---|
| Special characteristic |
Standard - Epoxy coated Zinc
|
| Second end termination style |
Cable
|
| Material of contact surface |
Gold
|
| Cable details |
Standard passive cable
|
|---|---|
| Assembly rating |
300V @ 8A (4 A NEC)
|
| Cable rating |
Thick: UL-Type PLTC 300V or CM 75 °C (167 °F) or AWM style 2464, CSAAWM I/II A/B 80 °C (176 °F) 300V FT1, class 2 Type, thick flex rated : UL-Type PLTC 75C or AWM 80C @ 600V, CSA AWM I/II A/B 80C @ 600V, FT4 oil res II, ODVA Type V, open-wiring compliant: UL
|
| Cable temperature |
-20 °C
|
|---|
| Type | Resource | Publication |
|---|---|---|
| General | Product Cutsheet | -- |
Looking for more documentation?
Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.
Search the Literature Library
- CE
- UL Recognized
This product was certified with the above certifications as of 2025-12-24. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.
Looking for more Technotes?
Find questions and answers from Rockwell Automation technical experts for this product in our Knowledgebase.
Search Knowledgebase
Technical Specifications
| Cable Length in Meters |
6,4M-7M
|
|---|
| Number of poles |
5
|
|---|---|
| Degree of protection (IP), mounted |
IP67
|
| Number of pins |
Standard 5-pin
|
| Second end conductors |
Standard 5 leads
|
| Number of conductors |
1 pair 15 AWG, 1 pair 18 AWG and drain
|
| Enclosure type rating |
NEMA 1, 2, 3, 4, 6P, 12, 13, IP67, 1200 psi (8720 kPa) washdown
|
| First end connector style |
Mini, straight male
|
| Cable diameter |
Thick: 12.2 mm, ODVA Type V: 13.5 mm
|
| Cable type |
Thick media, grey PVC
|
| Material |
Coupling nut: Epoxy-coated Zinc, jacket: grey PVC, contact: Gold-plated machined Brass
|
| Bend radius |
10 x diam
|
| Cable length |
6000 mm
|
|---|---|
| Special characteristic |
Standard - Epoxy coated Zinc
|
| Second end termination style |
Cable
|
| Material of contact surface |
Gold
|
| Cable details |
Standard passive cable
|
|---|---|
| Assembly rating |
300V @ 8A (4 A NEC)
|
| Cable rating |
Thick: UL-Type PLTC 300V or CM 75 °C (167 °F) or AWM style 2464, CSAAWM I/II A/B 80 °C (176 °F) 300V FT1, class 2 Type, thick flex rated : UL-Type PLTC 75C or AWM 80C @ 600V, CSA AWM I/II A/B 80C @ 600V, FT4 oil res II, ODVA Type V, open-wiring compliant: UL
|
| Cable temperature |
-20 °C
|
|---|
Documents
|
Product Cutsheet
General
-- |
| Type | Resource | Publication |
|---|---|---|
| General | Product Cutsheet | -- |
Looking for more documentation?
Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.
Search the Literature Library
Certifications
- CE
- UL Recognized
This product was certified with the above certifications as of 2025-12-24. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.
